Connectivity
4G/LTE, Wi-Fi
11.0kW Power
Voltage: 20V - 110V DC
Current : 125A DC
Charging Connector
IEC-62196-6
IS-17017-2-6 (LEVDC)
Protocol Standard
IEC-61851-25
IS-17017-25
OCPP 1.6J Complaint
Mobile-App & Web Portal Controls
Application
Electric 2W, 3W, 4W-Cargo
B2B-Logistics
For Charging Electric Vehicles at
Residential
Offices
Commercial
Destination
Top-Up Charging for Daily Delivery Vehicles
Top-Up Charging for Utility Vehicles
Regular Charging for Electric Tractors
Fast Charging of Off-Road Field Vehicles
Application
Product Specification
Input Voltage (AC)
400Vac (±10%), 3-Phase
Input Voltage (AC)
L1, L2, L3, N & PE (Earth)
Efficiency at Full load
> 94%
THD at Nominal Voltage & Full Load
< 5%
Output Voltage (DC)
20-110 VDC
Output Current
125A (for 55V-90V)
110A (for entire range)
Output Power
11.0 kW
Output Connector
IEC-62196-6 (Type-6)
IS-17017-2-6 (LEVDC)
with 2.0mtr cable
Over Current Protection
Power output is terminated upon detection of overcurrent
Residual Current Detection
30mA AC & 6mA DC
Electrical Protection
Over current, short circuit, Over voltage, Under voltage, Ground fault, Surge, and Over temperature protection
Energy Meter
Class 1.0
Charger & CMS
OCPP 1.6J with Over the Air Upgrade Support
Network Connection
4G/2G (SIM) and/or Wi-Fi
Charging Protocol
IEC-61851-25 & IS-17017-25 (Indian LEV-DC Standard)
Display
16x2 Character Display
Emergency Stop
Mushroom Type
User Authentication
Mobile App QR code & RFID (optional)
Visual Indications
Power, Charging, Fault Status
Operating Temperature
-10 to 55 degC
Ingress Protection
IP54
Altitude
≤ 2000 Mtr
Humidity
< 95%, non-Condensing
Standards
IS-17017-25, IEC-61851-25
Dimensions (W x H x D)
550mm x 400mm x 280mm
Weight
45.0 Kg without Cables and Charging Connector
Power Graph
Product Variants & Ordering Information
EVQPoint offers a highly versatile portfolio of variants that meet your charging needs.
Variants can be customized to meet your needs.
Please leave a message in contact us to customize your variant.
Accessories
EVQPoint offers a range of accessories that ease out your Station Installation & Regular Maintainance
DC Voltage
DC Current
Vehicle Connection Plug with 5mtr Cable
Model Name
IEC-62196-6 (Type-6)
Description of Item
Model Name
EVQP-ACC-32A-Cable-3Ph
3-core, 2.5 sq.mm cable with IEC-60309 connector on one-end and terminal pins on another end.
EVQP-ACC-Diag#
Diagnostics Tool for Service needs
High Efficiency
Peak efficiency > 94% aids in reducing energy consumption and lower operating costs
EMI / EMC Filter
Meets CISPR16-1-2 / EN55022 Standard
Safety & High Reliability
Robust protection for 20kV Surge, Short Circuit, Power Grid fluctuations
AC & DC Leakage Protection
Intelligent and High Precision Sensors with self checks built-in
Wider Temperature Operation
-10 to 55 degC Operation
Smart Diagnostic
Fault Diagnostics through both cloud interface -Charge Management System and Tools
Plug N Charge
Plug and Charge your vehicle without using App controls
Over the Air Upgrade (OTA)
Updates over the air through 4G/LTE
Customization
White Label & Enclosure customization as per your needs
Key Features
With high power efficiency and built-in intelligent controls, DC Fast chargers optimize the charging costs, provide robust safety, and offer a wider operating life cycle for the vehicle battery.
